Tuesday, August 31, 2021

Building a story or how a "narrative" is important in science I: in writing

 I found the below figure which I do not know the Author which I think can be useful to understand both what it is implied in writing a scientific paper and what is a theory, with respect to more simple analysis of data (or models, BTW). The first four arrangements of the data have some interest but, they do not capture much our interest. To do a gory example, is like to take an animal or a tree, separate them in parts and analyzing them from the point of view of the atoms it is made.  This information is real but it does not say anything crucial about the living being.  The being important think is realized when all the material is put together again (it would be great if the separation operation would be reversible) and it is analyzed in its "holistic" form and function.

So, it is for the topic of a paper. Usually we have a problem and we dissect it using a "reductionist" approach, but we are not able to put again the whole together and make sense of it. The reductionist action is usually not trivial at all, as the figure could, on the contrary, suggest, and the Authors are usually exhausted after having applied the techniques for doing it which could be experimentally and/or mathematically very complex.  But writing the paper needs the vision of the whole, the story to tell, and the discovery, in the rough matter,  of the sense. It is not a bottom-up action but more a top-down one, where hypothesis and deduction comes before than induction.
Therefore in writing a paper, we should first have an idea of the whole functioning, trying to get a working a logic from the elements we have in hands and see if they fit. At the first trial they will probably don't. Then we have to go back, refining our theory and trying again (and again).  After a while, the narrative, if we are patient and lucky, works. It is not necessary that it fully works. It is necessary that the final results is an appealing theory that can be further tested (or, better, falsified) in other cases and an improvement with respect to the actual knowledge. The steps forward are usually small.

Wednesday, August 18, 2021

GEOframe Summer School 2021 (moved to early Autumn for this year)

September 27 - September 28, 2021/ October 4 - October 7, 2021

Scientific Committee: Prof. Riccardo Rigon, Ph.D.; Prof. Giuseppe Formetta, Ph.D; Ing. Niccolò Tubini, Ing. Concetta d’Amato, Ing. Marialaura Bancheri, Ph.D.

Organizing Institutions:

Department of Civil, Environmental and Mechanical Engineering, University of Trento
Center Agriculture Food Environment, University of Trento
Institute for Agricultural and Forest Systems in the Mediterranean, National Research Council, Ercolano NA, Italy


The Earth’s Critical Zone (CZ) is defined as the heterogeneous, near surface environment in which complex interactions involving rock, soil, water, air, and living organisms regulate the natural habitat and determine the availability of life-sustaining resources (National Research Council, 2001). Clear interest in studying the CZ is spurred on by ever-increasing pressure due to the growth in human population and climatic changes.
Main topics will embrace the water flow (and heat transport) in porous media, the soil-plant-atmosphere continuum, and inverse problems. The aim of the course is to enable participants to run their own simulations with the GEOframe tools prepared to simulate the critical zone. They are process-based (e.g. Fatichi et al, 2016) tools, whose ambition is to simulate the processes of infiltration, heat transport and evaporation and transpiration. The GSS2021 deals mainly with the 1D tools and introduces the 2D ones called WHETGEO (1D and 2D), GEOframe-Prospero and LysGEO.
Besides the lectures and the hands-on sessions, the Summer School is the occasion for discussion and experience exchange among senior scholars and young researchers.
The School will be online on the Zoom platform.


Admissions are reserved to up to 30, PhD students and postdoctoral students, young researchers willing to learn the use of the GEOframe tools envisioned for the study of infiltration, energy budget, vegetation transpiration, water budget with process-based models

All students are asked to upload a CV and a motivation letter when applying.

The Summer School which is to be held in English, consists of 6 hours/day of activities for 6 days. The first two days, 27, 28 of September the installation of the GEOframe-OMS system tools and the general characteristics of the system. Lectures will be brief, dedicated to informatics and most of the time will be used for supporting participants’ installations.
The other four days will cover simulation of infiltration with WHETGEO-1D and 2D, with Prospero Transpiration model, and with the LysGEO model. There will be lectures on the hydrological processes implemented and applications to use cases.

Due to the Covid-19 emergency all the activities will be held via Zoom.


The cost is free for Students of the Hydrological Modelling Classes at the University of Trento, for Ph.D. students of the University of Trento DICAM and C3A programs, for the participants of the WATZON PRIN project and for all who wants to participate without having a certificate of GEOframe proficiency. Subscription to the class is necessary to receive the information to participate. For those who want the certificate, the Course costs 180 Euros. In any case the certificate is issued after the presentation of a small project of simulations for which appropriate tutoring will be given during and after the School.


For further information write to: abouthydrology@google.com or to the Secretary of the Class dott. Lorena Galante, lorena.galante@unitn.it


The GSS2021 talks and labs will be recorded and made publicly available during the School for self-training through the GEOframe blog (http://geoframe.blogspot.com).

Foreseen schedule

The details of the program are still to be defined

September 27-28:

These days are dedicated to those who never approached the GEOframe system and pursue the understanding of how it works. Who already knows how GEOframe works or have already installed it for different purposes than those of this School, can skip them

  • Introduction to the Object Modelling System and GEOframe Infrastructures (Verona 2022 environment)
  • Installation of OMS and GEOframe Verona
  • Brief introduction to Jupyter notebooks and Python
  • Few examples and Problem solving
October 4:

This morning is mostly dedicated to fill theory of the processes investigated by this School on GEOframe, meaning infiltration in soil, the basics of Richards/Richardson equation to which follow some exercises. The afternoon will be used to discuss issues related to the application of different boundary conditions, different parameterizations of the soil water retention curves.

Morning session
  • The Richardson-Richards equation
  • The equation and its parts, and three form of the equation
  • Soil Water Retention Curves
  • Hydraulic conductivity models
  • Numerical issues to keep in mind
Afternoon session
  • Practical session on Richardson-Richards equatio
  • one homogeneous layer
  • stratified layers
  • playing with boundary conditions
  • Presenting the results with Jupyter Notebooks
October 5:

This day is dedicated to discuss the problem of the surface boundary condition.

Morning session
  • Surface boundary condition and numerical issues
  • Practical session simulating:
  • Horton process
  • Dunnian process
  • Presenting the results with Jupyter Notebooks
Afternoon session
  • Individual exercises with support
October 6:

This day is dedicated to the bi-dimensional case of the Richardson-Richards equation and to present the radiation energy budget.

Morning session
  • Installing the software for building unstructured grids
  • Manage 2D unstructured grids.
  • Practical session on WHETGEO-2D on some pre-prepared cases
Afternoon session
  • Theory of radiation energy budget
  • Practical session on computing the radiation energy budget
October 7:

Day four is dedicated to the LysGEO model, evaporation and transpiration modelling and their coupling with R2.

Morning session
  • Evapotranspiration theory and equations in the Prospero model
  • Use of GEOframe - ET tools practices
Afternoon session
  • LysGEO theory
  • Practical session on LysGEO:
  • Comparison between potential ET and actual ET
  • Set different stress factors
  • Introducing vegetation traits

Specific Documentation

The specific documentation regards papers and thesis written on the GEOframe components used in this School. Other literature, of general interest, is provided within the presentations given during the course. Practical documentation for any of the tasks is provided by means of Jupyter Notebooks, of which the general ones are reported below.

Some essential about the Object Modelling System

Monday, August 16, 2021


 Karsts exist and cover approximately 15% of the Earth surface. Therefore it can happen very easily that in your hydrological analysis you across a Karst catchment. A general knowledge  of karst environment can be gained by reading the White, 2002 paper but, online you can find also the book by Ford and Williamson, 2007.They are quite comprehensive readings, not necessarily focused on the hydrology of the karst systems and how they can be modeled.

White (2000) propose a conceptual map of karst hydrology that is better represented later in Hartmann et al., Figure 4 (see below).

Precipitation falling into a karstic system can be divided into:

  • Allogenic recharge: precipitation that falls on non-carbonatic portion of the catchment and enter  the carbonate aquifer to the swallets
  • Disperse-diffuse infiltration directly happening on the karst surface and from there through the soil or the fractures
  • Internal runoff, falling into sinkholes drains
  • Flow from perched aquifers. Rainfall is collected by there aquifer and subsequently captured by vertical shaft or widen fractures in the vadose zone.

One important point  for hydrologists is to be able to recognize the karst geomorphology, e.g. Waele 2011,  to be able to automatically detect it and to treat differently from the rest of the catchment. Hofierka et al., 2018 offers a modern view (and very nice maps) on how to detect the areas presenting sink-holes (dolines) and so from IDAR topographic data. The topic of sinkholes detection, actually is sufficiently covered in literature, see, for instance,  other recent references are Pardo-Igúzquiza, 2013, Wu et al., 2016,  Zunpanoi et al., 2019.  It i s not clear to me at present if sinkholes  are  the only detectable manifestation of karst, but what I believe is that the decrease superficial erosion in karst area should also be recognizable, together with a disconnected or absent river network but on these specific topics, I did not find suitable references.
Where you have karst, you also  have springs. Even if they are not usually detectable by objective methods to find them (e.g. Geology Stack Exchange), many of them are already known from geological surveys and therefore a smart use of geological maps can help. It is self evident but hydrologist often rush to extract catchment and network characteristics without taking care of them in advance, as they should.
Karst formation are usually mapped,  geologists do their work  since long time ago, and we should use appropriately their information.

Coming to us, hydrologists measure rainfall and discharges and observe that the spring discharges of catchments affected by karst may look quite insensitive to rainfall variations. The direct way to investigate  the response of these catchment is to make leverage on tracer and tracers theory, as for instance reviewed in Hartmann et al., 2014, and shown in Zhang et al., 2021, or Nanni et al., 2020. These techniques, however, are well consolidated and known. For the desktop hydrologist,  something can be tried out with techniques of analysis of correlation between rainfall and discharge. Two notable contributions are Fiorillo and Doglioni, 2010 and Jukic and Denic-Jukic, 2015.  And another, more hydrological-hydrological, oriented to the determination of some characteristics time of catchments (not necessarily karst) is Giani et al., 2021.  More techniques for analyzing these time series, can be found in one previous post of this blog
From a practical point of view, what said so far would them urge the astute hydrologist to look for karst when delineating the catchments and subsequently do a careful time series analysis.

Finally, one like me wants to model the water budget. Even this case there exist a quite developed literature. The paper by White (2000) let us envision the typer of models which can be more process-based-groundwater oriented (Rooji, 2007, Hartmann et al, 2014)  or lumped, i.e. built on reservoir type of models (also Hartmann et al., 2014).
In the  more process-based type of models, the issue is put properly at work together the Darcian flow and the turbulent flow whose path is unknown and buried, hidden to our eyes which both contribute to the final flow. Because of the structure of the karst network, which is three-dimensional, threshold type of functioning can happen make the modelling more complex (Hartmann et al., 2014).
Lumped, ordinary differential equation  (ODEs) type of modelling is simpler but to be not too simple,  much heuristic has to be used to implement models that return reasonable behavior.  The high heterogeneity of the medium sometimes could help in simplifying the picture but just the real cases applications can discern what is acceptable. In both cases, obviously, the problem of parameter identification is the more important one.  There are several good examples of lumped model, well summarized by the paper of Hartmann et al, 2014  or, from a more practical point of view by the KarstMod model, Mazzilli et al., 2019 (please find its manual here). A careful reading of Hartmann et al 2014, can bring easily to a general conceptual model of karst in term of reservoirs. Rimmer et al, 2012, gives a few use case example of simple working models.  Butscher and Huggenberger, 2008 and Tritz et al, 2011 are some deployments of these models that can give some general guidance.

The high heterogeneity of the medium sometimes could help in simplifying the picture but just the real cases applications can discern what is acceptable.
In both cases, of using process-based modelling or lumped models, obviously, the problem of parameter identification is an important one.  Worldwide Karst data were made available by Olarinoye et al.,

If you do not have enough time, the best is to read White (2000),  De Waele, 2011 and Hartmann et al, 2014 papers first. If you have time for reading just one paper, read Hartmann et al. 2020.


Butscher, Christoph, and Peter Huggenberger. 2008. “Intrinsic Vulnerability Assessment in Karst Areas: A Numerical Modeling Approach.Water Resources Research 44 (3). https://doi.org/10.1029/2007wr006277.

Ford, Derek, and Paul Williams. 2007. Karst Hydrogeology & Geomorphology. Wiley.

Hartmann, A., N. Goldscheider, T. Wagener, J. Lange, and M. Weiler. 2014. “Karst Water Resources in a Changing World: Review of Hydrological Modeling Approaches.” Reviews of Geophysics 52 (3): 218–42.

Hofierka, Jaroslav, Michal Gallay, Peter Bandura, and Ján Šašak. 2018. “Identification of Karst Sinkholes in a Forested Karst Landscape Using Airborne Laser Scanning Data and Water Flow Analysis.Geomorphology 308 (May): 265–77.

De Waele, Jo, Francisco Gutiérrez, Mario Parise, and Lukas Plan. 2011. “Geomorphology and Natural Hazards in Karst Areas: A Review.Geomorphology 134 (1-2): 1–8.

Fiorillo, Francesco, and Angelo Doglioni. 2010. “The Relation between Karst Spring Discharge and Rainfall by Cross-Correlation Analysis (Campania, Southern Italy).Hydrogeology Journal 18 (8): 1881–95.

Giani, G., M. A. Rico‐Ramirez, and R. A. Woods. 2021. “A Practical, Objective, and Robust Technique to Directly Estimate Catchment Response Time.” Water Resources Research 57 (2). https://doi.org/10.1029/2020wr028201.

Mazzilli, N., V. Guinot, H. Jourde, N. Lecoq, D. Labat, B. Arfib, C. Baudement, C. Danquigny, L. Dal Soglio, and D. Bertin. 2019. “KarstMod: A Modelling Platform for Rainfall - Discharge Analysis and Modelling Dedicated to Karst Systems.Environmental Modelling and Software[R] 122 (103927): 103927.

Nanni, T., P. M. Vivalda, S. Palpacelli, M. Marcellini, and A. Tazioli. 2020. “Groundwater Circulation and Earthquake-Related Changes in Hydrogeological Karst Environments: A Case Study of the Sibillini Mountains (central Italy) Involving Artificial Tracers.” Hydrogeology Journal 28 (7): 2409–28.

Olarinoye, Tunde, Tom Gleeson, Vera Marx, Stefan Seeger, Rouhollah Adinehvand, Vincenzo Allocca, Bartolome Andreo, et al. 2020. “Global Karst Springs Hydrograph Dataset for Research and Management of the World’s Fastest-Flowing Groundwater.” Scientific Data 7 (1): 59.

Pardo-Igúzquiza, Eulogio, Juan José Durán Valsero, and Peter A. Dowd. 2013. “Automatic Detection and Delineation of Karst Terrain Depressions and Its Application in Geomorphological Mapping and Morphometric Analysis.Acta Carsologica 42 (1). https://doi.org/10.3986/ac.v42i1.637.

Rimmer, Alon, and Andreas Hartmann. 2012. “Simplified Conceptual Structures and Analytical Solutions for Groundwater Discharge Using Reservoir Equations.Water Resources Management and Modeling 2: 217–38.

Tritz, Sébastien, Vincent Guinot, and Hervé Jourde. 2011. “Modelling the Behaviour of a Karst System Catchment Using Non-Linear Hysteretic Conceptual Model.” Journal of Hydrology 397 (3): 250–62.

White, William B. 2002. “Karst Hydrology: Recent Developments and Open Questions.Engineering Geology 65 (2): 85–105.

Wu, Qiusheng, Chengbin Deng, and Zuoqi Chen. 2016. “Automated Delineation of Karst Sinkholes from LiDAR-Derived Digital Elevation Models.” Geomorphology 266 (August): 1–10.

Zhang, Zhicai, Xi Chen, Qinbo Cheng, and Chris Soulsby. 2021. “Using StorAge Selection (SAS) Functions to Understand Flow Paths and Age Distributions in Contrasting Karst Groundwater Systems.Journal of Hydrology 602 (November): 126785.

Zumpano, V., L. Pisano, and M. Parise. 2019. “An Integrated Framework to Identify and Analyze Karst Sinkholes.Geomorphology 332 (May): 213–25.

Wednesday, August 11, 2021

Causal Inferences and times series

 In the last post,  In the last post, moved by the necessity to compare time series, I browsed literature and my library of papers to find solutions to my needs (essentially I tried to understand if two time series are related by a time lag). In the search I found other things and my literature grew beyond the original scope. One direction that actually I had frequented previously was the one of distinguishing causal connections beyond just correlations. In my previous searches, I has been fascinated by the work by Judea Pearl and part of the findings inherited from his work. The theory of Pearl has been expressed in various part, including the 2000 paper and some books, that you can find in the references. His teachings were directly absorbed by Hannart and Noveau, themselves good statisticians working in climatology, who produced some papers (2016, 2017) using Judea's theory and notation.

The idea can be generalized fro two to multiple time series, as Eichler (2013) actually shows. Eichler actually is know to have produced such analysis in 2003. A trend of more recent paper on the topic are represented by  Jacob Runge (GS)  work , who also have the merit to have implemented and shared his TiGraMITe package. He also has got a prestigious ERC research program on this topic called Causal Earth. On the concepts he wants to develop in the ERC, he gave talks and produced may interesting papers, among those one in Nature and a second on in Science affiliated Journal (see below)

Because we like to do calculation not just read of write abstractly, we can find relief in the Causality handbook that can be a viable (open source) way to put in practice some of the ideas seen in the previous papers. A final, honorable mention goes also the the San Lian (2014) paper.


Dahlhaus, Rainer, and Michael Eichler. 2003. “Causality and Graphical Models in Time Series Analysis.Oxford Statistical Science Series, 115–37.

Eichler, Michael. 2013. “Causal Inference with Multiple Time Series: Principles and Problems.Philosophical Transactions. Series A, Mathematical, Physical, and Engineering Sciences 371 (1997): 20110613.

Hannart, A., J. Pearl, F. E. L. Otto, P. Naveau, and M. Ghil. 2016. “Causal Counterfactual Theory for the Attribution of Weather and Climate-Related Events.” Bulletin of the American Meteorological Society 97 (1): 99–110.

Hannart, A., and P. Naveau. 2017. “Probabilities of Causation of Climate Change.arXiv.v, December, 1–54.

Pearl, Judea, 2000. “Models, Reasoning and Inference.Cambridge, UK: CambridgeUniversityPress.

Runge, Jakob, Sebastian Bathiany, Erik Bollt, Gustau Camps-Valls, Dim Coumou, Ethan Deyle, Clark Glymour, et al. 2019. “Inferring Causation from Time Series in Earth System Sciences.Nature Communications 10 (1): 2553.

Runge, Jakob, Peer Nowack, Marlene Kretschmer, Seth Flaxman, and Dino Sejdinovic. 2019. “Detecting and Quantifying Causal Associations in Large Nonlinear Time Series Datasets.Science Advances 5 (11): eaau4996.

San Liang, X. 2014. “Causality between Time Series.arXiv [stat.ME]. arXiv. http://arxiv.org/abs/1403.6496.

Relations between 2 time series (thinking to rainfall-runoff)

 In investigating hydrological quantities, one interesting issue is to understand if two time series are correlated and especially if the correlation comes with a lag time, and, in case which is this lag time. This is nothing different than in many other analysis and, in fact the tools developed are ubiquitous in science. Looking for the how to correlate rainfall and discharges I stumbled in this ready-made post, "Four ways to quantify synchrony between time series data" by Jin Hyun Cheong, PhD.

The added value of this post is that the tools described are also available as open source Python scripts embedded in Jupyter Notebook and therefore anybody can re-execute them easily and learn as they work. I believe that when you go to apply the notebook to your data set it will not be hassle-free. However it is a good starting point. Certainly also you'll have to dig a little in literature to get the sense of what you were doing but this is a great starting point for those who needs to cope with this type of analyses. Jin Hyun material is available on OSF. Please, if you use it, cite it.

A second way to see their relation is to use the Kullback-Leibler mutual information, a concept derived form Information Theory (see also here) that you can find a little illustrated in the Veyrat-Charvillon and Standaert (2009) paper cited below. Here a notebook that teaches how to estimate it in Python using pyTOrch. Here a bottom-up calculation with standard Python.

The above time series analysis performed are quite interesting because they can also suggest new type of comparison between modelled and simulated time series if you start to get bored by the standard indicators of goodness of fit, like Kling-Gupta-Efficiency and Nash-Shutcliffe

If your main focus is the rainfall-runoff times series relationships, a recent paper to mention, is the one by Giani et al, below in References. But also the work of Serinaldi and Kilsby (2013) that seems quite complicate (boring or interesting? I still do not have read it) contains information.


Giani, G., M. A. Rico‐Ramirez, and R. A. Woods. 2021. “A Practical, Objective, and Robust Technique to Directly Estimate Catchment Response Time.” Water Resources Research 57 (2). https://doi.org/10.1029/2020wr028201.

Veyrat-Charvillon, Nicolas, and François-Xavier Standaert. 2009. “Mutual Information Analysis: How, When and Why?” In Cryptographic Hardware and Embedded Systems - CHES 2009, 429–43. Springer Berlin Heidelberg.

Serinaldi, Francesco, and Chris G. Kilsby. 2013. “The Intrinsic Dependence Structure of Peak, Volume, Duration, and Average Intensity of Hyetographs and Hydrographs.” Water Resources Research 49 (6): 3423–42.

Tuesday, August 10, 2021

How to learn (La)TeX

 If you want to know an interesting story, go and see what is TeX and why it was produced by Donald Knuth. It is a typesetting system with a language behind it, and the way most scientists who use mathematical formulas, write their paper (and equations). Actually, most of us use LaTeX the Leslie Lamport TeX, which is usually customized to obtain the desired layout by many journals. Native digital used to WYSIWYG can find strange the way it works but after a little practice, no one can really avoid to use it for formulas.

Assuming that I have convinced you (but my students SHOULD agree 😉 ) you have to learn it now. On the web there are many resources. Starting from the quickest,

Obviously there are several video tutorial available. The best thing for gettin them is that you Google "Latex Tutorial Video" by yourself. Any one for beginners can be found here:
Because TeX and Latex have their glorious history, there are several groups promoting them. The oldest one is the TeX user group, or, in brief, TUG

P.S. - Italians can also read the beautiful:
